High Volume Low Speed Fans from China Suppliers - Energy Efficient Ceiling Fans for Factories and Large Spaces
Product Features
Introduction to Industrial HVLS Fans
In the modern industrial landscape, maintaining optimal airflow and temperature control is crucial for productivity and employee comfort. Our Industrial HVLS (High Volume Low Speed) Fans are engineered to provide efficient air circulation in large spaces, making them an essential addition to any industrial facility. With a focus on energy efficiency and durability, our fans are designed to meet the demanding needs of various industrial applications.
Energy Efficiency and Cost Savings
One of the standout features of our Industrial HVLS Fans is their energy efficiency. Unlike traditional high-speed fans, HVLS fans operate at low speeds while moving a large volume of air. This design not only reduces energy consumption but also lowers operational costs. By circulating air effectively, these fans can help maintain a comfortable temperature, reducing the need for additional cooling systems. This translates to significant savings on energy bills, making our fans a smart investment for any industrial facility.
Large Coverage Area for Maximum Airflow
Our HVLS fans are specifically designed to cover expansive areas, making them perfect for warehouses, manufacturing plants, and distribution centers. With a single fan capable of moving air across a space of up to 20,000 square feet, you can ensure consistent airflow throughout your facility. This large coverage area helps eliminate hot spots and creates a more uniform temperature, enhancing the overall working environment.
Durable and Reliable Construction
Constructed from high-quality materials, our Industrial HVLS Fans are built to withstand the rigors of industrial use. The robust design ensures longevity and reliability, even in challenging environments. Each fan undergoes rigorous testing to ensure it meets our high standards for performance and durability. This commitment to quality means you can trust our fans to deliver consistent airflow for years to come.
Technical Specifications of the Aloemax, Aloepro, and Aloeplus Series
Aloemax Series
| Model | Size (M) | Motor Power (KW) | Fan Rotation Range (RPM) | Max Air Volume (M³/Min) | Effective Coverage Area (Air speed ≥ 1M/S) | Rated Voltage (V) | Rated Current (A) | Fan Weight (KG) | Noise Level (dB) | Energy Consumption (KW·H) |
|---|---|---|---|---|---|---|---|---|---|---|
| Aloemax7.3 | 7.3 | 1.5 | 10-58 | 13850 | 1100 | 380/220 | 3.4 | 120 | 40 | 1.5 |
| Aloemax6.1 | 6.1 | 0.8 | 10-60 | 12000 | 1000 | 380/220 | 2.9 | 102 | 40 | 0.8 |
| Aloemax5.5 | 5.5 | 0.8 | 10-65 | 11000 | 850 | 380/220 | 2.8 | 85 | 40 | 0.75 |
| Aloemax4.9 | 4.9 | 0.8 | 10-70 | 10000 | 700 | 380/220 | 2.7 | 80 | 40 | 0.75 |
| Aloemax4.2 | 4.2 | 0.4 | 10-75 | 9000 | 550 | 380/220 | 2.0 | 68 | 40 | 0.4 |
| Aloemax3.8 | 3.8 | 0.4 | 10-85 | 8000 | 450 | 380/220 | 2.0 | 65 | 40 | 0.4 |
| Aloemax3.3 | 3.3 | 0.4 | 10-95 | 7000 | 400 | 380/220 | 2.0 | 60 | 40 | 0.35 |
| Aloemax2.5 | 2.5 | 0.3 | 10-100 | 5000 | 300 | 220 | 2.0 | 55 | 40 | 0.3 |
Aloeplus Series
| Model | Size (M) | Motor Power (KW) | Fan Rotation Range (RPM) | Max Air Volume (M³/Min) | Effective Coverage Area (Air speed ≥ 1M/S) | Rated Voltage & Current | Fan Weight (KG) | Noise Level (dB) | Energy Consumption (KW·H) |
|---|---|---|---|---|---|---|---|---|---|
| Aloeplus7.3 | 7.3 | 1.5 | 10-58 | 13850 | 1100 | 380V/3.3A | 127 | 42 | 1.5 |
| Aloeplus6.1 | 6.1 | 1.5 | 10-60 | 12500 | 1000 | 380V/2.5A | 112 | 42 | 1.5 |
Aloepro Series
| Model | Size (M) | Motor Power (KW) | Fan Rotation Range (RPM) | Max Air Volume (M³/Min) | Effective Coverage Area (Air speed ≥ 1M/S) | Rated Voltage (V) | Rated Current (A) | Fan Weight (KG) | Noise Level (dB) | Energy Consumption (KW·H) |
|---|---|---|---|---|---|---|---|---|---|---|
| Aloepro7.3 | 7.3 | 1.5 | 10-60 | 13650 | 1000 | 380/220 | 3.4 | 113 | 40 | 1.45 |
| Aloepro6.1 | 6.1 | 0.8 | 10-65 | 11500 | 900 | 380/220 | 2.9 | 100 | 40 | 0.75 |
| Aloepro5.5 | 5.5 | 0.8 | 10-70 | 10500 | 800 | 380/220 | 2.8 | 82 | 40 | 0.7 |
| Aloepro4.9 | 4.9 | 0.8 | 10-80 | 9800 | 700 | 380/220 | 2.7 | 80 | 40 | 0.7 |
| Aloepro4.2 | 4.2 | 0.4 | 10-90 | 8900 | 550 | 380/220 | 2 | 69 | 40 | 0.4 |
| Aloepro3.8 | 3.8 | 0.4 | 10-95 | 7900 | 450 | 380/220 | 2 | 67 | 40 | 0.4 |
| Aloepro3.3 | 3.3 | 0.4 | 10-100 | 6950 | 400 | 380/220 | 2 | 64 | 40 | 0.35 |
| Aloepro2.5 | 2.5 | 0.3 | 10-120 | 4950 | 300 | 220 | 2 | 53 | 40 | 0.3 |
Frequently Asked Questions (FAQ)
What is the advantage of HVLS fans over traditional high-speed fans?
HVLS (High Volume Low Speed) fans operate at low speeds while moving a much larger volume of air. This design significantly reduces energy consumption, lowers operational costs, and provides more consistent temperature control across expansive spaces compared to traditional high-speed fans.
How much coverage area can a single Industrial HVLS Fan provide?
A single large-scale HVLS fan is capable of circulating air effectively across a coverage area of up to 20,000 square feet, making them ideal for large warehouses, manufacturing plants, and distribution centers.
What are the main differences between the Aloemax, Aloeplus, and Aloepro series?
The series differ mainly in their motor power configurations, rotational speed ranges (RPM), and structural weight. For instance, the Aloemax series offers sizes down to 2.5m, the Aloeplus series focuses on high-power 1.5KW configurations, and the Aloepro series offers a wider selection of RPM ranges (up to 120 RPM for the smaller models).
What voltage supply is required for these industrial fans?
Most models in the Aloemax, Aloeplus, and Aloepro series support standard industrial rated voltages of 380V or 220V, depending on the specific model and regional power requirements of your facility.
Are these HVLS fans noisy during operation?
No. Despite their large size, all models in these series are engineered for quiet operation, maintaining a low noise level of approximately 40 to 42 dB, which is highly comfortable for industrial working environments.
